Exact Engineering
The Ultimate Multi-Axis Bar Machine
Powerful 5-axis turn/mill center with Fanuc 32i-T with i-HMI control and Eurotech custom software, featuring main spindle 30 HP/51 mm or 54 HP/71mm, sub-spindle 34 HP, 20 HP live tools and 10,000 RPM, 15-station turret, up to 90 tools with EGS/Y-Axis
The Ultimate Multi-Axis Bar Machine.
Powerful Main and Sub Spindles
Built for Speed, Capacity, and Complete-Part Machining
The B620 51-SLY combines a 34 HP main spindle with 5,000 RPM performance on both the main and sub spindles, providing the power and speed needed to machine complex parts efficiently from both sides.
With a 51 mm bar capacity, 9.8" machining diameter, 24.4" machining length, and 27.5" maximum swing diameter, this machine gives shops the strength, accuracy, and work envelope needed for demanding production applications.
Custom Eurotech Software
Infinitely Customizable
Operating within the robust Fanuc iHMI control system, our custom software is designed to be exceptionally user-friendly yet powerful, allowing for seamless customization of machining processes. This adaptability ensures that the Ultima can be tailored to meet the intricate demands of any part.
Chip Conveyor / Tool Probe
More Automation, Less Labor
The Ultima includes a chip conveyor as well as a tool probe which can perform in-process checks as well as make offsets where necessary so you can run unattended on even tight tolerance parts.
Programmable Gantry
Less hands, more output
The programmable parts evacuation system is engineered for precision engagement, ensuring gentle handling of parts, reducing any possible denting/scuffing. The gantry takes the finished part from the sub-spindle and unloads it directly onto a parts conveyor that passes the part to a secondary part conveyor to eliminate part damage and parts jamming...significantly increasing throughput.
Gap Elimination Software
Slash Cycle Times
Developed meticulously by our skilled engineers, our Gap Elimination Logic software eradicates forced dwells in the cycle. Experience seamless transitions between operations like turning, C-axis, and Y-axis movements, where others struggle with time-consuming dwells. Ensure continuous operation, even during parts catch, by keeping tools engaged and productive.
Eurotech Gang Tool System — EGS
Maximum Tooling Flexibility with EGS
The BMX Ultima’s 15-station turrets provide 15 total turret stations. When combined with the machine’s large true Y-axis capability and the Eurotech Gang Tool System (EGS), the Trofeo can support up to 120 cutting tools, giving manufacturers exceptional flexibility for complex parts, reduced tool changes, and one-operation machining.
Included Hardware
Feature Eight Heading
Eurotech-Fanuc EASY Plus Control, 15” LCD color touch screen and full keyboard
“C” axis with brake on both main and sub-spindle
True Y-axis on solid box ways
ASA 5" sub-spindle (built-in) with coolant flush
Chip conveyor with 3.5 bar wash-down coolant pump + 7 bar coolant pump for the turret
Bar feeder interface
Automatic tool presetter
SBS tool monitoring system combined with tool life and wear management
Polygon turning on main spindle
Damage protection software (airbag)
Pneumatic parts ejector on sub-spindle (100 mm stroke)
Free tooling package including static/live holders
Eurotech custom macros
Rotary magnetic scales on main and sub-spindle
And much more!
Delivers superior threading performance not commonly available from competing flat bed lathes - ideal for oilfield and power industry components.
Machines with up to 65 feet between centers and the ability to handle parts up to 90,000 pounds, making them the go-to solution for extreme part sizes and heavy-duty applications.
-
Additional guideways provide greater stability and support for the workpiece
-
Enhanced vibration damping ensures higher accuracy
-
Better load distribution extends machine life and cutting consistency
-
The structural integrity allows for tighter tolerances and smoother finishes even under the most aggressive cutting conditions.
Built for oil & gas, power generation, rail, shipbuilding, aerospace, and other large-format machining sectors.
Manufactured by our partner in Italy - known across Europe for quality, innovation, and performance.
-
